crazy belgian · Snailer Joined: 25 Nov 2008 Posts: 45

Hello i already started building my project for the next worldmeeting in Tsjechië because after my project in Italy some people tried to build 2cv's as low or lower as mine .Now i will try to set a new standard in low rider 2CV building .

I already started channeling the body and i built the airride in the original spring position it is now working fine ,the airride lifts the car about 30cm
i adjusted the front arms so the connection to the airspring has more force because the distance between the rotation point on the front arm and the connection pin is 4 cm extra so this gives me more than 30% extra pulling force afterwards i dont really think it was neccesary .

Last week i narrowed the front axle in total 11cm and i already made 13 inch wheels with different offset between front and rear because i want to go much lower as before i did some special stuff so my 13 inch wheel comes over my steering pins in front and in the rear my my inside part of 2cv wheel comes out of the rear 13 inch wheel because the more the tire is on the inside the lower you can go in the rear fender .

i will post more pictures next week

crazy belgian · Snailer Joined: 25 Nov 2008 Posts: 45

more pictures

crazy belgian · Snailer Joined: 25 Nov 2008 Posts: 45

backfire · Posted: Mon Dec 22, 2008 12:59 am Post subject:

great stuff, but is the airride already working and is the car moving or was it very cold and you have the shakes Laughing

_________________
2CV, with Visa turbo charged

Etienne · Hoodrider Joined: 25 May 2007 Posts: 2829

Cool!
I would like to see the front axle! And a video of the car taking off too ! Cool

Can't wait to be summer 2009 to see it finish!
_________________
www.super2cv.com

Fredo · Posted: Mon Dec 22, 2008 11:32 am Post subject:

Beautiful project, your car marked me well in Vinadio. Very Happy

Olli · Posted: Mon Dec 22, 2008 1:02 pm Post subject:

Great to see that you are getting fenders back! Very Happy

-Olli
_________________
www.ollierkkila.com

bounns · Snailer Joined: 04 Feb 2008 Posts: 13

it's so beautifull a love it ..!!!!
i will look your post with very interest because i want make this on my 2cv6
_________________

CWG fever : http://cwg.skynetblogs.be/
t-shirt et stickers dispo

crazy belgian · Snailer Joined: 25 Nov 2008 Posts: 45

http://www.youtube.com/watch?v=rBvgaAaCqt4

here is the video of the working airride ,still have to make the wiring but it works great we tested it levelling two adults and 200kg of steel in the front and it went up easy.

Olli · Posted: Wed Dec 24, 2008 12:26 am Post subject:

Looking great! Cant wait to hear results from drive! what sort of air bags? are you having?

-Olli
_________________
www.ollierkkila.com

JoZeF · Grave Digger Joined: 25 May 2007 Posts: 1734

looking cool

well done !
_________________
"That bumper fits there like sunglasses on pig" Laughing

O.E.

crazy belgian · Snailer Joined: 25 Nov 2008 Posts: 45

I am using 10cm diagonal size cilinders and i use four of them ,i just replaced the original spring with these they have a 10cm travel and this lifts the car about 30cm.

When the car is completely lowered it is still possible to drive because in the rear i have 3cm space to the rear wing and in front about 2cm and my chassis is 4-5 cm from the ground

I sell these cilinders to build your own airride they cost about 90 euro a piece , today i sold a set to my brother in law and i will help him build it to his mehari it is the white mehari with chrome delta mics.

ebus · Dropped Joined: 24 Aug 2007 Posts: 136

so cool
I had already imagined a similar trick but I never passed to the practice
what I dont understand, it's the pisition of the bags in High position when they are deflated they are packed in your carter??

ebus · Dropped Joined: 24 Aug 2007 Posts: 136

backfire · Posted: Wed Dec 24, 2008 11:19 am Post subject:

I don't quit get what you mean Ebus, but I assume that our crazy belgian is using air cilinders, they are not packed with any kind of bag, but they use a piston. The air chamber i guess is in front of the piston, so when you fill it with air the car raises.
